| Housing: | Cylindrical |
| Thread size: | M12 x 1 |
| Sensing range Sn: | 4 mm |
| Assured sensing range Sa: | 3.24 mm |
| Installation type: | Flush |
| Switching frequency: | 2,000 Hz |
| Switching output: | PNP |
| Output function: | NO |
| Electrical wiring: | DC 3-wire |
| Enclosure rating: | IP 67 1) |
| Connection type: | Cable, 3-wire, 2 m |
| Housing: | Standard |
| Supply voltage: | 10 V DC … 30 V DC |
| Ripple: | ≤ 10 % |
| Voltage drop: | ≤ 2 V |
| Power consumption: | ≤ 10 mA 1) |
| Time delay before availability: | ≤ 100 ms |
| Hysteresis: | 5 % … 15 % |
| Repeatability: | ≤ 2 % 2) 3) |
| Temperature drift (of Sr): | ± 10 % |
| EMC: | According to EN 60947-5-2 |
| Output current Ia: | ≤ 200 mA |
| Cable material: | PVC |
| Short-circuit protection: |  |
| Reverse polarity protection: | |
| Power-up pulse protection: | |
| Shock/vibration: | 30 g, 11 ms/10 Hz … 55 Hz, 1 mm |
| Ambient operating temperature: | -25 °C … 75 °C |
| Housing material: | Metal, Nickel-plated brass |
| Housing cap material: | Plastic, PA6 |
| Housing length: | 63 mm |
| Thread length: | 48 mm |
| Tightening torque, max.: | 12 Nm |
