- Symbol 00991619
- Approval RCM trademark c UL us listed (OL)
- CE mark (see declaration of conformity) To EU EMC Directive In accordance with EU RoHS Directive
- CE marking (see declaration of conformity) To UK instructions for EMC To UK RoHS instructions
- Special characteristics Oil resistant
- Note on materials RoHS-compliant
- Measuring principle Magnetic reed
- Ambient temperature -40 °C … 70 °C
- Switching output Contacting, bipolar
- Switching element function N/O contact
- Max. output current 500 mA
- Max. output current using mounting kits 80 mA
- Max. switching capacity AC10 VA
- Max. switching capacity DC10 W
- Max. switching capacity DC using mounting kits 2.4 W
- Max. switching capacity AC using mounting kits 2.4 VA
- Voltage drop 1.17 V
- Short circuit current rating no
- Overload protection Not available
- Operational voltage range AC5 V … 30 V
- Operational voltage range DC5 V … 30 V
- Reverse polarity protection no
- Electrical connection 1, connection type Cable
- Electrical connection 1, number of connections/cores 3
- Electrical connection 1, type of mounting Screw-type lock
- Electrical connection 1, connection pattern 00991155
