Product characteristics
| Type of light | red light |
| Housing | threaded type |
Application
| Special feature | Background suppression |
| Function principle | Diffuse reflection sensor |
Electrical data
| Operating voltage [V] | 10…36 DC |
| Current consumption [mA] | 25 |
| Protection class | II |
| Reverse polarity protection | yes |
| Type of light | red light |
Outputs
| Electrical design | PNP |
| Output function | light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 150; (200 (…60 °C)) |
| Switching frequency DC [Hz] | 1000 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Range [mm] | 15…300; (white paper 200 x 200 mm 90% remission) | |
| Range on white object (90 % remission) [mm] | 15…300 | |
| Range on grey object (18 % remission) [mm] | 15…290 | |
| Range on black object (6 % remission) [mm] | 15…190 | |
| Factory setting |
| |
| Range adjustable | yes | |
| Max. light spot diameter [mm] | 25 | |
| Light spot dimensions refer to | at maximum range | |
| Background suppression available | yes |
