Product characteristics
| Type of light | infrared light |
| Housing | threaded type |
Application
| Special feature | Function check output |
| Function principle | Diffuse reflection sensor |
Electrical data
| Operating voltage [V] | 10…36 DC |
| Current consumption [mA] | < 35 |
| Protection class | II |
| Reverse polarity protection | yes |
| Type of light | infrared light |
| Wave length [nm] | 880 |
Outputs
| Electrical design | PNP |
| Output function | light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Function check output | yes |
| Max. voltage drop of function check output [V] | 3.5 |
| Max. current load for function check output [mA] | 10 |
| Permanent current rating of switching output DC [mA] | 200 |
| Switching frequency DC [Hz] | 320 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Range [mm] | 1…200; (white paper 200 x 200 mm) |
| Range adjustable | yes |
| Max. light spot diameter [mm] | 92 |
| Light spot dimensions refer to | at maximum range |
Operating conditions
| Ambient temperature [°C] | -25…60 |
| Protection | IP 65 |
